Specifications
- Specifications/Standards: Feed mechanism: Spindle linear type
- Measurement data output function available
- Measuring surface with carbide alloy tip
- Constant pressure device included
- Measurement range (mm): 50-80
- Minimum display (mm): 0.001
- Maximum permissible error (μm): ±3
- Power supply: Button-type silver oxide battery SR44 No.938882 (1 unit included as standard, for operation check)
- Manufacturer code: 293-668-20
- Constant pressure device: Yes
- a: 10.3
- b: 47 c: 2.8
- L: 50
- Position detection method: Capacitive absolute encoder
- Parallelism (μm): 2
- Flatness (μm): 0.3
- Maximum response speed: Unlimited
- Minimum display unit (mm): 0.001
- Measuring force (N): 5~12
- Model number: MDQ-80MX
- Battery life: Approximately 5 years under normal use
- Weight/Weight unit: 480g
- Set contents/Accessories: 1 reference rod
- Country of origin: Japan
