Specifications
- Specifications/Standards: No measurement data output terminal
- Measurement range (mm): 0-25
- Minimum display (mm): 0.001
- Maximum permissible error (μm): ±1
- Protection class: IP65
- Power supply: Button-type silver oxide battery (SR44) x 1 (included)
- Manufacturer code: 293-244-30
- Measuring surface shape: Standard type
- Constant pressure device: Ratchet thimble
- Power supply (V): Button-type silver oxide battery (SR44) x 1 (included)
- a: 6.5 b: 25
- c: 2.5
- L: 0
- Position detection method: Electromagnetic induction rotary encoder
- Parallelism (μm): 1
- Flatness (μm): 0.3
- Minimum display unit (mm): 0.001
- Measuring force (N): 7~12
- Model number: MDC-25PXT
- Battery life: Approximately 2.4 years under normal use
- Weight/Weight unit: 280g
- Set contents/Accessories: Spanner (No. 301336) 1 piece
- Country of origin: Japan
