Specifications
- Specifications/Standards: With constant pressure device
- Measuring surface has carbide alloy tip
- Measuring range (mm): 0-25
- Minimum display (mm): 0.001
- Maximum permissible error (μm): ±1
- Manufacturer code: 102-311
- Measuring surface shape: Standard type
- Constant pressure device: Ratchet stop
- Parallelism (μm): 1
- Flatness (μm): 0.3
- Measuring force (N): 5-10
- Graduation (mm): 0.001 (with vernier scale)
- Symbol: M320-25AA
- Weight/Weight unit: 180g
- Set contents/Accessories: Spanner (No. 301336) x 1 (measuring range 0-25mm, 25-50mm), Spanner (No. 200877) x 1 (measuring range 50-75mm, 75-100mm)
- Country of origin: Japan
