Specifications
- Specifications/Standards: Measurement data output terminal included
- BMD-MX has an IP65 protection rating.
- Equipped with a constant pressure device.
- Measurement range (mm): 50-75
- Minimum display (mm): 0.001
- Maximum permissible error (μm): ±2
- Protection rating: IP65
- Power supply: Button-type silver oxide battery (SR44) x 1 (included)
- Manufacturer code: 395-273-30
- Measuring surface shape: Double spherical type (with carbide alloy tip)
- Constant pressure device: Ratchet stop
- Power supply (V): Button-type silver oxide battery (SR44) x 1 (included)
- Minimum measurable inner diameter (mm): 19
- Position detection method: Electromagnetic induction rotary encoder
- Minimum display unit (mm): 0.001
- Model number: BMD-75MX
- Battery life: Approximately 2.4 years under normal use
- Weight: 470g
- Set contents/accessories: 1 reference rod (excluding measurement range 0-25mm), 1 spanner (No. 301336)
- Country of origin: Japan
