Specifications
- Specifications/Standards: Measurement data output terminal included
- Constant pressure device included
- Measurement range (mm): 0-25
- Minimum display (mm): 0.001
- Maximum permissible error (μm): ±3
- Power supply: Button-type silver oxide battery (SR44) x 1 (included)
- Manufacturer code: 422-260-30
- Feeding mechanism: Spindle linear type
- Measuring surface shape: Blade type
- Constant pressure device: Ratchet stop
- Power supply (V): Button-type silver oxide battery (SR44) x 1 (included)
- a: 11
- b: 31
- C: 12.5
- L: 0
- Position detection method: Electromagnetic Inductive rotary encoder (BLM-MX), Capacitive absolute encoder (BLM-QMX)
- Tip shape: Type B
- Parallelism (μm): 3
- Minimum display unit (mm): 0.001
- Model number: BLM-25MX/0.4T
- Battery life: Approximately 2.4 years under normal use (BLM-MX), approximately 5 years under normal use (BLM-QMX)
- Weight: 365g
- Set contents/accessories: Spanner (No. 301336) x 1 (BLM-MX)
- Country of origin: Japan
Note: For US buyers, import duties are included in the price. For buyers outside the US, import duties are not included in the price.
