Specifications
- Specifications/Standards: Measuring surface with carbide tip
- Constant pressure device included
- Measuring range (mm): 100-125
- Minimum display (mm): 0.01
- Maximum permissible error (μm): ±3
- Manufacturer code: 103-141
- Measuring surface shape: Standard flat type (with carbide tip)
- Constant pressure device: Ratchet stop
- Minimum display: 0.01mm
- b: 79
- c: 5.3
- L: 100
- Parallelism (μm): 3
- Flatness ( μm): 0.6
- Measuring force (N): 5~10
- Graduation (mm): 0.01
- Symbol: OM-125
- Weight/Unit of mass: 0.515 kg
- Set contents/Accessories: 1 reference rod (excluding measuring range 0~25 mm), 1 spanner (No. 301336) (maximum measuring length 300 mm or less), 1 spanner (No. 200154) (maximum measuring length 325 mm or more)
- Country of origin: Japan
