Specifications
- Specifications/Standards: No measurement data output terminal
- Measurement range (mm): 25-50
- Minimum display (mm): 0.001
- Maximum permissible error (μm): ±1
- Protection class: IP65
- Power supply: Button-type silver oxide battery (SR44) x 1 (included)
- Manufacturer code: 293-241-30
- Measuring surface shape: Standard type
- Constant pressure device: Ratchet stop
- Power supply (V): Button-type silver oxide battery (SR44) x 1 (included)
- a: 7.3
- b: 3 2.5
- c: 2.5
- L: 25
- Position detection method: Electromagnetic induction rotary encoder
- Parallelism (μm): 1
- Flatness (μm): 0.3
- Minimum display unit (mm): 0.001
- Measuring force (N): 5~10
- Model number: MDC-50PX
- Battery life: Approximately 2.4 years under normal use
- Weight/Weight unit: 330g
- Set contents/Accessories: 1 reference rod, 1 spanner (No.301336)
- Country of origin: Japan
