Specifications
- Specifications/Standards: Flatness: 0.6 μm
- Minimum counter display: 0.01 mm
- Measuring surface with carbide tip
- Equipped with constant pressure device
- Measuring range (mm): 25-50
- Minimum display (mm): 0.01
- Maximum permissible error (μm): ±2
- Manufacturer code: 193-102
- Measuring surface shape: Standard type (with carbide tip)
- Constant pressure device: Ratchet stop
- Minimum display: 0.01 mm
- b: 32.5
- c: 2
- L: 25
- Parallelism (μm): 2
- Flatness (μm): 0.6
- Graduation (mm): 0.01
- Symbol: M810-50
- Weight/Unit of weight: 275 g
- Set contents/Accessories: 1 reference rod (excluding measuring range 0-25 mm), 1 spanner (No. 301336)
- Country of origin: Japan
